SPL-80 Filter Disc Technical Specification
Product Description
The SPL-80 filter disc is designed for filtration systems handling high-viscosity melts, effectively removing hard impurities and agglomerates. Constructed from stainless steel sintered felt and stainless steel sintered mesh, the SPL series filter discs are reusable and withstand repeated cleaning.
The SPL series filter discs are mainly used for oil filtration in filter presses, as well as oil line systems in marine vessels, diesel engines, and other industrial equipment. They are also applied in the chemical fiber industry—placed upstream of various spinning nozzles during synthetic and regenerated fiber textile processing—to filter impurities from spinning solutions under similar operational conditions.
Technical Parameters & Requirements (SPL-80)
-
Filtration Rating: 5 μm – 400 μm
-
Key Features: High flow rate and high filtration efficiency
-
Filter Media: Phosphor bronze mesh, stainless steel plain weave mesh, twill weave mesh, Dutch weave mesh, etc.
-
Mesh Range: 80 mesh to 363 mesh (Custom specifications available upon request)
-
Max Operating Temperature: ≤ 95°C
-
Max Operating Pressure: ≤ 0.8 MPa
-
Cleaning Pressure Drop: ≤ 0.15 MPa
Applications
-
Ideal for filtration in various models of thin-oil lubrication systems.
-
Suitable for oil line system filtration in filter presses, marine vessels, diesel engines, and similar equipment.
-
Applicable across various industrial fields—including petroleum, power generation, chemical engineering, and metallurgy—to enhance oil cleanliness.
